| Technical specifications |
| CPU(The processor) |
Samsung Exynos4412 Quad core basic frequency 1.4GHz |
| The operating system |
Android 4.2.2 |
| Memory capacity |
RAM：DDR3 1GB NandFlash：4GB |
| Micro SD（TF）card extand to 32G |
| Display |
3.5 IPS display, The resolution of the 320×480 |
| Keyboard |
24（include Num.、Functionand power），2 user-defined key |
| The battery |
3.7V 4000mAh lithium polymer battery； 6000ｍAh for selection(可选) |
| Size |
156mm（length）×72mm（width）×31mm（thick） |
| Weight |
312g(include 4000mAh battery) |
| Camera |
80 w megapixel camera with flash |
| Micro card(卡槽) |
Micro SD（TF）×1、SIM×1、PSAM×1 |
| Indicator light |
Power Indicator light×1 |
| Physical interface |
USB 2.0×1，multi-function interface（support USB，RS252、RS485 and etc.）×1 |
| audio |
speaker×1，microphone×1，headphone×1 |
| Tel function |
Support wonderful mobile telephone function |
| Vibration |
OK |
| SCANNING specifications |
| Barcode system |
1D |
Code 39，Codabar，Code 128，Discrete 2 of 5，Interleaved 2 of 5，Code 93，UPC-A，UPC-E，EAN-8，EAN-13，MSI，EAN-128，ISBN/ISSN and etc. |
| 2D |
1D：
Code 39，Codabar，Code 128，Discrete 2 of 5，Interleaved 2 of 5，Code 93，UPC-A，UPC-E，EAN-8，EAN-13，MSI，EAN-128，ISBN/ISSN and etc.
2D：
PDF417，QR Code(QR1，QR2，Micro QR)，Data Matrix，GS1-DataBarTM(RSS-Limited，RSS-14，RSS-14 Stacked，RSS-Expand) and etc. |
| NFC/RFID |
Support ISO/IEC 18092，ISO/IEC 21481，ISO/IEC 14443 Types A，B，B’，JIS(X)6319-4，ISO/IEC 15693 and etc. |
| WiFi |
IEEE 802.11a/b/g/n，support 2.4GHz、5.0GHz double frequency |
| Bluetooth |
The built-in Bluetooth 4.0+EDR |
| location |
GPS/A-GPS，Big Dipper |
| Infrared communication |
38K Carrier infrared communication |
| GPRS/3G |
WCDMA，CDMA2000，GPRS，GSM |
| Environmental parameter |
| working temperature |
-10°C~+50°C |
| storage temperature |
-25°C~+70°C |
| relative humidity |
5%RH ~ 95%RH(Without dew) |
| levels of protection |
IP65（1.5M Anti drop） |
| accessories |
charger *1，lithium polymer battery *1，USB data string*1，band wrist straps *1 |
